Our high-performance magnetic drive gear pumps deliver pulsation-free, precision fluid transportation with an innovative gear-driven system designed for continuous accuracy. Featuring exceptional vacuum suction capacity and high conveying pressure, these pumps ensure stable and reliable transport of low-viscosity liquids, making them suitable for medium and high-pressure applications. The leak-proof design, utilizing magnetic drive and static seals, isolates the medium from the external environment, ensuring leak-free operation. Available in various configurations and materials, these pumps cater to diverse industrial need.

The package comes in with pump and pump drive.  If you have any questions, feel free to speak to our product specialist.

Key Features:

• Inaccuracy: +/-0.5%
• Max. Flow rate: 1.5 L/min (DI water)
• Excellent corrosion resistant to organic solvents
• Pump materials:
• Pump body: SS304/SS316
• Gear material: PEEK and shaft SS316; PEEK and ceramic
• Fluid connection: 1/4" NPT
• Viscosity range: 0.2 - 3000 CPs
• Liquid temperature: -30℃-120℃
• Max. Differential Pressure:  15 Bar
• Voltage: 24VDC

• Power: 40W
• Drive mode: External driver
• Filter recommended:400mesh on inlet
• Motor speed:
• 0-4000 RPM
• Inlet vacuum: -0.85 Bar

• Pump displacement:
• 0.35 mL/rev  (1.5 L/min)
• 0.9 mL/rev   (3.0 L/min)
• 1.41mL/rev   (6.0 L/min)
• Seal material: PTFE or FKM
• Pump motor:
• Brushless DC motor
• Stepper motor
• Servo motor
• Compliant certificates:
• CE and ROHS

Typical Applications:

• Food and Beverage
• Cosmetics
• Inkjet Printing
• Life Sciences
• Chemical Metering
• Analytical Equipment
• Fuel Cell Technology
• Diesel Engine Emissions Control
