The pressure regulator generates an accurate pressure that can be used to drive a liquid flow at a stable flow rate. The 2-channel, highly integrated pressure controller has a built-in pressure pump, solenoid valves, pressure regulators, a rotary valve, and pressure sensors. The system is able to simultaneously supply up to 2 independent channels with positive pressures. This system can work as a standalone machine controlled by the front buttons and knobs. It can also be controlled by the included program communicated through a TTL serial communication interface. Wi-Fi and Bluetooth modules are embedded.
Key Features
- Easy to use and quick to set up
- Built‐in pressure pump
- External pressure source connector available
- Multi-channel liquid distributors
- Multi-channel control of external valves
- Analogical and digital input/output
- Real-time pressure/switch monitors
- Two communication ports available for flow rate sensors
- Panel control of integrated elements
- Programmable off‐line operation
- Online control with graphic interface
- TTL Serial Output
- Bluetooth and Wi-Fi modules embedded
- 4KB EPPROM (for numerical sequence storage)
- 1G SD card memory (for data storage)
- User graphical interface (GUI)
- Network operation: The remote control is feasible with Bluetooth, wireless or Ethernet using smartphones, tablets and other terminals
- Easily communicate with other instruments and commonly used devices such as NI-DAQ modules, CCD cameras, spectrometers, electrochemical station, etc. for monitoring or feedback control.
Typical Applications
- Micro-liter volume liquid handling or delivery
- In Vivo sampling with micro-dialysis solution
- Integration with analytical instruments for sample preparation
- Auto sampling for in vitro diagnostics (IVD)
- Other precision metering applications
- Droplet generation application
| Pressure Pump | 3.0 mbar - 2.0 bar |
| External Pressure Source Port | 1 |
| Pressure Regulators | 2, with accuracy +/-0.5 mbar |
| Solenoid Valves | 2, with response time 100 ms |
| Pressure Sensors | 2 |
| Voltage Outputs | 8, up to 12 V |
| Analog Inputs/Outputs | 3/3 |
| RS232 Connectors | 2, with 5, 12, and 24 VDC power supply |
| Gas Flow Rate | 0 - 1.1 L/min |
| Liquid Flow Rate | 0 - 10 mL/min (depends on resistance) |
| Flow Sensor Communication | 2 port available |
| Working Temperature | 10 - 50 ℃ |
| Working Humidity | 20-80% RH |
| Minimum PC Configuration | Intel Core i5-4xxx, 4G RAM, Win7, USB2.0 |
| Support Software | C++, Matlab, Android, Arduino |
| Communication | WiFi and Bluetooth modules |
| Overall Dimension | 150 mm x 150 mm x 250 mm |
| Weight | 2.0 Kg |
Pressure Regulator Flow Controller Multi-Functional 2-Channels For Microfluidics
- Product Code: ASP-FC-PLV2
- Availability: In Stock
-
$8,894.00
