Minitech’s advanced stepper driver is based on a DSP with an advanced control algorithm. It brings a high level of system smoothness, providing optimum torque and nulls mid-range instability. Motor auto-identification and parameter auto-configuration technology offers optimum responses with different motors and is easy-to-use. The driven motors can run with much lower noise, less heating, smoother movement than most of the drivers in the markets. Its unique features make the driver more attractive.

Key Features

• High Performance, Based on DSP Algorithm.
• Anti-Resonance, provides optimum torque and nulls mid-range instability
• Motor auto-identification and parameter auto-configuration technology, offers optimum responses with different motors
• Multi-Stepping allows a low resolution step input to produce a higher microstep output for smooth system performance
• Microstep resolutions programmable, from full-step to 51,200 steps/rev
• Can be set by Dip switch (2,4,8,16,32,64,128,256,5,10,25,50,125,250)
• Supply voltage up to +36 VDC
• Output current programmable, from 0.5A to 4.2A(Can be set by Dip switch too)
• Pulse input frequency up to 200 KHz
• TTL compatible and optically isolated input
