The LFM1PP01M‑TS is a high‑precision, multi‑mode peristaltic pump engineered for demanding fluid‑handling applications. Its wide flow‑rate range supports everything from ultra‑low microliter dosing to high‑volume transfers, making it suitable for laboratory, industrial, and process environments. A high‑torque motor enables the use of multi‑stacked pump heads for expanded channel capacity, while the 5‑inch touchscreen provides full parameter control, real‑time status display, and intuitive navigation.

Key Features

• Wide Flow‑Rate & Volume Range: 0.1 µL to 99,999 L
• High‑Torque Drive: Supports multi‑stacked pump heads for increased channel count
• External Control Options: Start/stop, direction, and speed via 4–20 mA, 0–5 VAC, 0–10 VAC, or 0–10 kHz
• Leak Detection: Visual indicator with optional audible alert
• Online Adjustment: Real‑time flow‑rate and volume changes during operation
• Communication: RS485 for system integration
• Power Supply: 100–240 VAC, 50/60 Hz

Speed Range

• Speed Range: 0.01-150 RPM, CW/CCW
• 0.1 RPM (0.1–99.9 RPM)
• 1 RPM (100–600 RPM)

User Interface

• 5‑inch touchscreen with full parameter setup and live operating display
• Operating Modes:  Multi‑flow modes for continuous, timed, and volume‑based dispensing

Advanced Calibration

• Multi‑point calibration ensures precise and repeatable flow‑rate accuracy across all ranges
• Prompt Function: Automatically displays flow‑rate range based on current settings

Compliance & Reliability

• IP Rating: IP31
• EMC Compliance: Certified
• Warranty: 2 years
• Operating Temperature: 0–40°C
• Relative Humidity: 20–85%

Typical Applications:

• Precise reagent dispensing
• Cell culture media transfer
• Buffer and solvent delivery
• Chromatography system feeding
• Sample preparation and dilution workflows
• Bioreactor feeding and harvesting
• Fermentation nutrient dosing
• pH adjustment chemical dosing
• Chemical metering and additive injection
• Nutrient injection for fermentation
• Diagnostic reagent delivery
• Controlled micro‑volume dispensing for assay systems
