The SPE vacuum manifolds are designed to process 12 or 24 samples in parallel. As a tool used for sample preparation, the precise and individual pressure control enables easy conditioning, sample loading, washing and elution steps of solid phase extraction. 12-port and 24-port manifold options are available.
Key Features
- Unique flow path design to ensure stable vacuum and flow rates
- Individual valves control the flow rate independently to avoid cross-contamination
- Attached pressure gauge to monitor vacuum level
- Maximum vacuum of 80KPa
- The height of the test tube rack can be adjusted to meet the needs of different capacities.
- Compatible with a large capacity collector to concentrate mass samples rapidly (refer to the specification
Typical Applications
- Sample preparation in SPE
| Model | ASP-SPEMF12G | ASP-SPEMF24G-S |
| Port Number | 12 | 24 |
| Glass Vacuum Chamber | Quartz | Quartz |
| Maximum Vacuum | -80KPa | -80KPa |
| Pressure Range | 0-80KPa | 0-80KPa |
| Test Tubes | ≤ 105mm, Φ10/Φ13/Φ15 | ≤ 105 mm, Φ10/Φ13/Φ15 |
| Thumb | File information |
 |
SPE Vacuum Manifold 12 and 24 Ports.pdf File Size 163.87KB |
Biocomma Solid Phase Extraction (SPE) Vacuum Manifolds, 12 Ports
- Brand: Biocomma
- Product Code: ASP-SPEMF12GS
- Availability: In Stock
- $640.98
-
$576.80
