• Adapters & Connectors: Pre-Determined Torque Flangeless Fittings,  1/4''-28/ M6 Threads, PP/PTFE Material,   30 Pieces/Pk
    Adapters & Connectors: Pre-Determined Torque Flangeless Fittings,  1/4''-28/ M6 Threads, PP/PTFE Material,   30 Pieces/Pk Adapters & Connectors: Pre-Determined Torque Flangeless Fittings,  1/4''-28/ M6 Threads, PP/PTFE Material,   30 Pieces/Pk

Medical grade flangeless fittings are used for low pressure applications  (up to 0.8MPa or 116PSIG).  They come with pre-determined torque nuts and ferrules. The built-in torque control allows users to prevent over-torqued on the fittings and damage to the flow path and increase fluidics system robustness.

There are two materials available: polypropylene (PP) or Polytetrafluoroethylene (PTFE). Both 1/4''-28 UNF and M6 threads options are offered for different applications.  This item includes 30 pieces of the adapter.  Minimum quantity of order: 5 packs










Polypropylene (PP)

  • Temperature: Can be sterilized at 100°C and can be used below 62 °C
  • Chemical stability:  can used to acid, alkali, salt, alcohol and other organic solvents


Polytetrafluoroethylene (PTFE):

  • Wide operation temperature allowed: ~ 180 -250°C
  • Better chemical resistance:  can be used in organic solvents, corrosion or acid/alkali
  • Non-toxic and electrical insulation
Fitting and Connector
Model No. ASP-700700
Material PP/PTFE (Medical Grade)
Color Natural PP/PTFE
Thread 1/4''-28 UNF or M6
Pressure Rating @ 20 ºC 116 PSI/0.8MPa
Tubing OD 1.6mm/2.0mm/2.5mm/3.0mm/3.2mm.
Qty. 30 /Pk
